Venev Archer³ -Serie Metallic CBN Stone [6 "x 1"]

Vollbildmodus

Heiß

Neu

Auf Lager

Vorbestellung

Venev Archer³ -Serie Metallic CBN Stone 6 "x 1"

Venev Industrial Diamonds, 💎6" Steine und Strohhalme, 🛒Vollständiger Katalog, 🧊6" Superabrasives

Highlights

🏹ARCHER³ SERIES – 6" x 1" Single-Sided Metallic-Bonded CBN

📊AVAILABLE GRITS: F43 (300 µm), F80 (180 µm), F100 (140 µm), F150 (90 µm), F240 (45 µm), F400 (18 µm), F800 (6 µm), F1200 (2.5 µm)

⚗️METAL MATRIX COMPOSITE BINDER – SiC/BC-reinforced copper-tin bronze MMC

🥪SINGLE-SIDED – 4 mm abrasive layer mounted on 3 mm aluminum blank

📐FOR SYSTEMS – Working surface: 150 x 25 mm (6" x 1") Edge Pro form-factor

SKU: SGR-CBN-80

VERFÜGBARKEIT: Nicht auf Lager

$122.00 USD

Streugut:80

80

150

240

400

800

Noch $50.00 USD zu kostenlosem Versand.

Free Shipping
on orders over $50

Returns in 14 Days
following delivery date

Military Discounts
active, retired, veterans

Details

Brand

Venev Industrial Diamonds

Series

Archer³

Form Factor

6" Single Sided Edge Pro

Backing

Anodized aluminum blank compatible with Edge Pro

Working Surface

152 x 25mm (6" x 1")

Total Thickness

6mm

Abrasive

Cubic boron nitride

Binder

MS-1 - Copper-tin alloy metal matrix composite reinforced with silicon carbide. MB-1 - copper-tin alloy metal matrix composite reinforced with boron carbide.

Material Thickness

3mm

Recpmmended Routine

Water

Grit Rating 📊:

Extra Coarse Coarse Medium Fine Extra Fine

Available Grits:

F80F150F240F400F800

Grit Scale:

# Grit (FEPA)

Abrasive Standards:

FEPA-F (grit designation) and GOST 9206-80 (regional standard)

Description

Venev Archer³ Series Metallic CBN Sharpening Stones are used for sharpening knives made of any steel using guided knife sharpeners (Hapstone, TSPROF, and other Edge Pro-compatible sharpening systems). Venev Archer³ ('Archer Cubed') consists of a 3mm-thick CBN-bearing plate mounted on an Edge Pro aluminum base. CBN (Cubic Boron Nitride) is the second-hardest material after diamond. The CBN-bearing plate contains evenly distributed CBN grains with copper-tin alloy bonding for high endurance and low wearing rate.

All Venev stones use FEPA-F grit classification. Archer³ series is available in 5 grits: F80 to F800. For grits above F800, Orion Series resin-bonded stones are recommended.

Information

CBN's qualities include high levels of high hardness, strength, abrasion resistance, and thermal and chemical resistance. These characteristics exceed the values of synthetic diamonds and conventional abrasives such as silicon carbide and aluminum oxide. In particular, CBN's high thermal stability and chemical resistance make it suitable for sharpening in conditions where synthetic diamonds are not normally employed.

CBN offers excellent performance in sharpening knives of any steel. Due to its high resistance specs, CBN can be used dry without lubricant. This makes CBN the cleanest of the available sharpening stones.

How to use

Metallic CBN can be used without lubricants.

Metallic CBN stones may have tone imperfections. Metallic CBN may become darker over time due to natural metal oxidizing, but it does not affect the sharpening.

Metallic CBN stones do not require any preparations.

Venev Product Matrix

Code	Diamond Series	CBN Series	Dimensions	Bond	Class
CBR	Cerberus		100×17×10×2×2	Resin	Dual‑sided Premium
UMI	Ursa		150×16×10×1×1	Resin	Dual‑sided Standard
CEN	Centaur	Centaur³	150×25×10×1×1	Resin	Dual‑sided Standard
MON	Unicorn🚀	Unicorn³🚀	150×25×14×3×3	Resin	Dual‑sided Premium
CMA	Greater Dog		98×40×10×1×1	Resin	Dual‑sided Standard
PHE	Phoenix		200×83×10×1×1	Resin	Dual‑sided Standard
DRA	Dragon		200×83×12×2×2	Resin	Dual‑sided Premium
CHA	Chameleon🚀	Chameleon³🚀	150×25×6×3×3	Metallic	Dual‑sided Solid
SCO	Scorpion		100×25×8×2	Resin	Single‑sided Mounted
ORI	Orion	Orion³	150×25×6×3	Resin	Single‑sided Mounted
SGR	Archer 𝘎𝘦𝘯𝟤⌛	Archer³	150×25×3	Metallic	Single‑sided Variative
GEM	Gemini 𝘎𝘦𝘯𝟤🚀		150×12×3 R40	Metallic	Single‑sided Mounted
SCL	Sculptor🚀		150×12×3	Metallic	Single‑sided Mounted

Resin Dual Premium Resin Dual Standard Resin Single Mounted Metallic Dual Solid Metallic Single Mounted 🚀 Released ⌛ Soon

Dimensions notation.
Monolayer solid abrasives have 3 numbers: length × width × thickness.
Single-sided abrasives with backing have 4 numbers: length × width × full thickness × thickness of abrasive.
Dual-sided abrasives have 5 numbers: length × width × full thickness × thickness of abrasive #1 × thickness of abrasive #2 (both sides)
If thickness is variable, the minimum thickness is noted.
For curved abrasives, a radius of curvature inmm is added: R40.

Metallic Binders (MMC)

M2-01 - Copper-tin bronze alloy.
MS-1 - Metal-matrix composite (MMC) - Copper-tin bronze alloy reinforced with silicon carbide.
MB-1 - Metal-matrix composite (MMC) - Copper-tin bronze alloy reinforced with boron carbide.
MS-1A - Metal-matrix composite (MMC) - Aluminum-copper alloy reinforced with silicon carbide.

Resin Binders

B1-10 - Boron-modified phenolic resin (BPF) composite - Made of powdered bakelite, copper additive
B2-01 - Boron-modified phenolic resin (BPF) composite - Made of liquid bakelite, iron additive (softer than В1-10)
В2-01М - Boron-modified phenolic resin (BPF) composite - Made of liquid bakelite, copper additive (softer than В2-01)
OSB (OCB) – A proprietary phenolic resin composite.

(OSB and OCB refer to the same binder; the difference arises from a transliteration quirk of the Cyrillic “ОСБ,” which can be rendered as either “OSB” or “OCB” in Latin script.)
